Marine GPS Antenna / GA-800

GA-800 Marine GNSS Active Antenna

Brief description

GA-800 is a marine GNSS Antenna equipped with the high-sensitive patch antenna, its durable and stable structure design provides stable and high-quality transmitting performance.


  • Supports GPS, QZSS, GLONASS, and Galileo systems
  • Substantial and environmental-resistance structure
  • IP68 grade waterproof
  • Cable Length & Connector are customizable

Product description

GA-800 is designed for the Marine Vessels mast or tall buildings that require long extra cables without signal constraint to the GPS receivers. It is the integration of the high performance GNSS patch antenna and a low noise amplifier into an extremely fully waterproof enclosure. The GA-800 is compatible with most GPS/GNSS receivers with 2.8~3.7V DC input power.

It can receive all existing public GNSS signals, including GPS, GLONASS, and Galileo as well as QZSS L1, and provide excellent antenna signal amplification and out-band filtering with rejection for that receiver at 2.8V DC or 3.7V DC input Voltage.
