ANT-191-4G-5G Outdoor 4G/LTE-5G Antenna
Brief description
ANT-191-4G-5G is the omni-directional design provides high gain without the cellular tower location and alignment hassles of directional antennas. Improves transmit & receive signals for all 4G/LTE & 5G frequencies.
Features
- Support 600-6000 MHz Coverage
- 10 dBi Peak Gain
- IP67 stable and durable structure design
- Cable Length & Connector are customizable
- Robust UV Resistant PC enclosure and base
Product description
The ANT-191-4G-5G easy-to-install outdoor and improves transmit & receive signals for all 4G/LTE & 5G frequencies on Verizon, AT&T, T-Mobile, Bell Mobility, Rogers, Telus, Telcel, Movistar, Digicel and others.
SkyNav ANT-191-4G-5G is an omni-directional design permanent mount antenna for vehicle roof and offsure vessel applications. It is compatible with Mi-Fi Hotspots, external 4G/5G cellular modems, routers and signal amplifiers from Cisco, Cradlepoint, Digi, Inseego, MoFi, Netgear, Pepwave, and Sierra.
The 5G/4G antennas also include backward compatibility to work at most worldwide 2G and 3G bands.
|
Specification |
|
| Size |
191mm*191mm*83mm |
| 4G/5G Frequency | 600~6000 MHz |
| Input Impedance | 50ohm |
| Return Loss | -10 dBi |
| VSWR Port 1&2 | 2.5:1 MAX |
| 4G/5G Gain | 6/7/10dBi (with 20cm cable) |
| Efficiency (%) 4G/5G |
600~2700MHz: 46%~97% 3000~4000MHz:62%~86% 4000~6000MHz:55%~96% |
| Operating Temperature | -40oC to +85oC |
|
Cable |
5M CFD200 BLACK |
| Connector | SMA-male |
| Ingress Protection | IP67 |
| Radome Material & Color | UV Resistant PC Black |
| Mounting Pole | M20 15P |
